| SIZE | LOAD INDEX/ SPEED SYMBOL | STD. RIM | TREAD DEPTH | SECTION WIDTH MM | OVERALL DIAMETER | MAX LOAD | PRESSURE | ||
|---|---|---|---|---|---|---|---|---|---|
| kgs | lbs | kPa | PSI | ||||||
| 315/80R22.50 | 156/150M | 9 | 14.5 | 312 | 1076 | 4000 | 3350 | / | / |
| 700R16 | 118/ 114L | 5.5 | 11 | 202 | 768 | 1320 | 1180 | / | / |
| 750R16 | 122/118L | 6.00G | 13 | 215 | 805 | 1500 | 1320 | / | / |
| 825R16 | 128/124K | 6.50H | 13 | 235 | 855 | 1800 | 1600 | / | / |
| 285/70R19.5 | 146/144M | / | / | / | / | / | / | / | / |
| 825R20 | 128/124K | 6.50H | 13 | 235 | 855 | 1800 | 1600 | / | / |
| 900R20 | 144/142K | 7 | 15.5 | 259 | 1019 | 2800 | 2650 | / | / |
| 1000R20 | 149/146K | 7.5 | 16.5 | 278 | 1054 | 3250 | 3000 | / | / |
| 1100R20 | 152/149K | 8 | 16 | 293 | 1085 | 3550 | 3250 | / | / |
| 1200R20 | 158/155F | / | / | / | / | / | / | / | / |
| 11R22.5 | 148/145M | 8.25 | 14.5 | 268 | 1054 | 3150 | 2900 | / | / |
| 11R22.50 | 149/146M | / | / | / | / | / | / | / | / |
| 12R22.5 | 152/149M | 9 | 14.5 | 300 | 1085 | 3550 | 3250 | / | / |
| 13R22.5 | 156/150L | 9.75 | 15.5 | 320 | 1124 | 3750 | 3450 | / | / |
| 295/80R22.5 | 152/149M | 9 | 14.5 | 298 | 1044 | 3550 | 3250 | / | / |
| 315/80R22.5 | 156/150M | 9 | 14.5 | 312 | 1076 | 4000 | 3350 | / | / |
| 1200R24 | 160/157K | 8.5 | 15 | 315 | 1226 | 4500 | 4125 | / | / |
