| Size | Rim | Ply Rating | Inflated tyre dimension | Static Loaded Radius | Rollin Circum. | Load Index | Inflated Pressure | Recommended load, kg | ||||||||||||
| SW | OD | Speed | bar | Speed, (km/h ) | ||||||||||||||||
| (mm) | (mm) | (mm) | (mm) | Symbol | Free Rolling | Drive wheel | ||||||||||||||
| 10 | 20 | 25 | 30 | 40 | 50 | 10 | 20 | 25 | 30 | 40 | 50 | |||||||||
| 10.0/75-15.3 | 10.2″ | 14 | 775 | 365 | 2400 | 5.5 | 130 A8 | 1900/1320 | / | / | / | / | / | / | / | / | / | / | / | / |
| 11.5/80-15.3 | 11.5″ | 14 | 870 | 395 | 2580 | 4.75 | 139 A8 | 2430/1700 | / | / | / | / | / | / | / | / | / | / | / | / |
| 10.5-20 | 10.6″ | 12 | 955 | 445 | 2880 | 4.3 | 135 B | 2180 | / | / | / | / | / | / | / | / | / | / | / | / |
| 12.5-20 | 12.8″ | 12 | 1040 | 475 | 3090 | 4 | 140 B | 2500 | / | / | / | / | / | / | / | / | / | / | / | / |
| 14.5-20 | 14.0″ | 14 | 1098 | 505 | 3260 | 3.5 | 143 B | 2725 | / | / | / | / | / | / | / | / | / | / | / | / |
