| Size | Rim | Ply Rating | Inflated tyre dimension | Static Loaded Radius | Rollin Circum. | Load Index | Inflated Pressure | Recommended load, kg | ||||||||||||
| SW | OD | Speed | bar | Speed, (km/h ) | ||||||||||||||||
| (mm) | (mm) | (mm) | (mm) | Symbol | Free Rolling | Drive wheel | ||||||||||||||
| 10 | 20 | 25 | 30 | 40 | 50 | 10 | 20 | 25 | 30 | 40 | 50 | |||||||||
| 6.00-16 | 83 | 8 | 4.5 | TT | / | 170 | 745 | 545 | 4.5 | A8/40 kmph | / | |||||||||
| 6.50-16 | 105 | 8 | 4.5 | TT | / | 180 | 765 | 925 | 3.7 | A8/40 kmph | / | |||||||||
| 7.50-16 | 108 | 8 | 5.5 | TT | / | 190 | 810 | 1120 | 4 | A8/40 kmph | / | |||||||||
| 7.50-16 | 108 | 8 | 5.5 | TT | / | 190 | 810 | 1120 | 4 | A8/40 kmph | / | |||||||||
| 7.50-18 | 117 | 8 | 6 | TT | / | 214 | 854 | 1285 | 4.7 | A8/40 kmph | / | |||||||||
| 16.9-30 | 137 | 8 | 15 | TT | / | 429 | 1485 | 2300 | 1.8 | A6/30 kmph | ||||||||||
| 18.4-30 | 139 | 8 | 16.2 | TT | / | 467 | 1560 | 2430 | 1.4 | A6/30 kmph | / | |||||||||
| 18.4-34 | 144 | 10 | 16 | TT | / | 467 | 1660 | 2800 | 1.8 | A6/30 kmph | / | |||||||||
| 18.4-34 | 142 | 8 | 16 | TT | / | 467 | 1660 | 2650 | 1.4 | A6/30 kmph | / | |||||||||
| 13.6-38 | 139 | 12 | 12 | TT | / | 345 | 1565 | 2430 | 3 | A6/30 kmph | / | |||||||||
| 13.6-38 | 131 | 8 | 12 | TT | / | 345 | 1565 | 1950 | 2 | A6/30 kmph | / | |||||||||
| 18.4-38 | 143 | 8 | 16 | TT | / | 467 | 1770 | 2725 | 1.4 | A6/30 kmph | / | |||||||||
| 20.8-38 | 160 | 14 | 18 | TT | / | 528 | 1840 | 4500 | 2.5 | A6/30 kmph | / | |||||||||
