| Size | Rim | Ply Rating | Inflated tyre dimension | Static Loaded Radius | Rollin Circum. | Load Index | Inflated Pressure | Recommended load, kg | ||||||||||||
| SW | OD | Speed | bar | Speed, (km/h ) | ||||||||||||||||
| (mm) | (mm) | (mm) | (mm) | Symbol | Free Rolling | Drive wheel | ||||||||||||||
| 10 | 20 | 25 | 30 | 40 | 50 | 10 | 20 | 25 | 30 | 40 | 50 | |||||||||
| 500/60R22.5 | AG16.00 | / | 503 | 1172 | 530 | 3571 | 155D | 4 | / | / | / | / | / | / | / | / | / | / | / | / |
| 560/60R22.5 | AG16.00 | / | 543 | 1244 | 561 | 3810 | 164D | 4 | / | / | / | / | / | / | / | / | / | / | / | / |
| 600/50R22.5 | AG20.00 | / | 611 | 1172 | 532 | 3479 | 159D | 4 | / | / | / | / | / | / | / | / | / | / | / | / |
| 600/55R26.5 | AG20.00 | / | 620 | 1336 | 608 | 4050 | 165D | 4 | / | / | / | / | / | / | / | / | / | / | / | / |
