| Size | Rim | Ply Rating | Inflated tyre dimension | Static Loaded Radius | Rollin Circum. | Load Index | Inflated Pressure | Recommended load, kg | ||||||||||||
| SW | OD | Speed | bar | Speed, (km/h ) | ||||||||||||||||
| (mm) | (mm) | (mm) | (mm) | Symbol | Free Rolling | Drive wheel | ||||||||||||||
| 10 | 20 | 25 | 30 | 40 | 50 | 10 | 20 | 25 | 30 | 40 | 50 | |||||||||
| 280/85R20 | W10 | / | 285 | 984 | 445 | 2914 | 112A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 280/85R20 | W10 | / | 285 | 984 | 445 | 2937 | 112D | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 320/85R20 | W11 | / | 320 | 1052 | 472 | 3123 | 119D/122A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 280/85R24 | W10 | / | 285 | 1086 | 496 | 3235 | 115A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 280/85R24 | W10 | / | 285 | 1086 | 496 | 3235 | 115D/118A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 320/85R24 | W11 | / | 325 | 1154 | 523 | 3444 | 122D/125A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 340/85R24 | W12 | / | 355 | 1188 | 537 | 3527 | 125A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 340/85R24 | W12 | / | 355 | 1188 | 542 | 3528 | 125D/128A | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 380/85R24 | W12 | / | 385 | 1260 | 571 | 3725 | 131D/134A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 380/85R24 | W12 | / | 385 | 1260 | 527 | 3729 | 131A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 420/85R24 | W15 | / | 450 | 1324 | 597 | 3931 | 137D | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 280/85R28 | W10 | / | 285 | 1187 | 546 | 3552 | 118A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 320/85R28 | W11 | / | 330 | 1255 | 574 | 3698 | 124A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 320/85R28 | W11 | / | 325 | 1255 | 574 | 3746 | 124D | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 340/85R28 | W12 | / | 355 | 1289 | 592 | 3847 | 127A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 340/85R28 | W12 | / | 355 | 1289 | 592 | 3847 | 127D | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 380/85R28 | W12 | / | 390 | 1357 | 621 | 4035 | 133A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 380/85R28 | W12 | / | 390 | 1357 | 620 | 4035 | 133D | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 420/85R28 | W15L | / | 450 | 1425 | 648 | 4224 | 139A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 420/85R28 | W15L | / | 450 | 1425 | 648 | 4253 | 139D/142A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 380/85R30 | W12 | / | 385 | 1408 | 646 | 4195 | 135A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 380/85R30 | W12 | / | 385 | 1408 | 646 | 4195 | 135D/138A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 420/85R30 | W12 | / | 450 | 1476 | 673 | 4385 | 140A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 420/85R30 | W15L | / | 450 | 1476 | 673 | 4405 | 140D | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 460/85R30 | W16L | / | 480 | 1544 | 701 | 4574 | 145A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 460/85R30 | W15L | / | 480 | 1544 | 701 | 4584 | 145D/148A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 320/85R34 (12.4R34) | W12 | / | 385 | 1510 | 697 | 4516 | 141A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 380/85R34 | W12 | / | 385 | 1510 | 697 | 4516 | 137A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 380/85R34 | W12 | / | 385 | 1510 | 697 | 4516 | 137D/140A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 420/85R34 | W15L | / | 450 | 1578 | 725 | 4705 | 142A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 420/85R34 | W15L | / | 450 | 1578 | 725 | 4705 | 142D | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 460/85R34 | W15L | / | 480 | 1646 | 752 | 4895 | 147D/150A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 340/85R38 | W12 | / | 355 | 1543 | 719 | 4620 | 133D/135A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 420/85R38 | W15L | / | 450 | 1680 | 775 | 5026 | 144A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 460/85R38 | W16L | / | 480 | 1747 | 796 | 5214 | 149A8/B | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 460/85R38 | W15L | / | 480 | 1747 | 796 | 5214 | 149D/152A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 520/85R38 | DW16 | / | 530 | 1855 | 847 | 5513 | 155D/158A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 650/85R38 | DW23B | / | 675 | 2071 | 947 | 6181 | 173D/176A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 520/85R42 | DW16L | / | 530 | 1951 | 888 | 5823 | 157D/160A8 | 1.6 | / | / | / | / | / | / | / | / | / | / | / | / |
