| Size | Rim | Ply Rating | Inflated tyre dimension | Static Loaded Radius | Rollin Circum. | Load Index | Inflated Pressure | Recommended load, kg | ||||||||||||
| SW | OD | Speed | bar | Speed, (km/h ) | ||||||||||||||||
| (mm) | (mm) | (mm) | (mm) | Symbol | Free Rolling | Drive wheel | ||||||||||||||
| 10 | 20 | 25 | 30 | 40 | 50 | 10 | 20 | 25 | 30 | 40 | 50 | |||||||||
| 7.50-16 | 5.50F x 16 | 6 | 215 | 805 | 372 | 2400 | 88 A8 | 2.2 | / | / | / | / | / | / | / | / | / | / | / | / |
| 9.5-20 | W8 | 8 | 241 | 945 | 434 | 2810 | 107 A8 | / | / | / | / | / | / | / | / | / | / | / | / | / |
| 11.2-24 | W10 | 8 | 282 | 1103 | 516 | 3309 | 116 A8 | 2.4 | / | / | / | / | / | / | / | / | / | / | / | / |
| 12.4-24 | W11 | 8 | 307 | 1159 | 542 | 3477 | 121 A8 | 2.3 | / | / | / | / | / | / | / | / | / | / | / | / |
| 12.4-24 | W11 | 12 | 307 | 1159 | 542 | 3477 | 129 A8 | 3.5 | / | / | / | / | / | / | / | / | / | / | / | / |
| 12.4-24 | W10 | 10 | 285 | 1103 | 516 | 3309 | 120 A8 | 3 | / | / | / | / | / | / | / | / | / | / | / | / |
| 13.6-24 | W12 | 8 | 345 | 1210 | 560 | 3555 | 122 A8 | 1.9 | / | / | / | / | / | / | / | / | / | / | / | / |
| 14.9-24 | W13 | 8 | 402 | 1275 | 597 | 3825 | 128 A8 | 1.8 | / | / | / | / | / | / | / | / | / | / | / | / |
| 16.9-24 | W15L | 8 | 426 | 1330 | 622 | 3990 | 133 A8 | 1.7 | / | / | / | / | / | / | / | / | / | / | / | / |
| 16.9-24 | W15L | 8 | 426 | 1330 | 622 | 3990 | 133 A8 | 1.7 | / | / | / | / | / | / | / | / | / | / | / | / |
| 9.5-24 | W8 | 8 | 241 | 1050 | 491 | 3150 | 112 A8 | 2.8 | / | / | / | / | / | / | / | / | / | / | / | / |
| 9.5-24 | W8 | 8 | 241 | 1050 | 491 | 3150 | 112 A8 | 2.8 | / | / | / | / | / | / | / | / | / | / | / | / |
| 18.4-26 | / | 10 | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / |
| 18.4-26 | W16L | 12 | 492 | 1480 | 693 | 4440 | 146 A8 | 2.3 | / | / | / | / | / | / | / | / | / | / | / | / |
| 23.1-26 | DW20 | 18 | 587 | 1605 | 738 | 4670 | 162 A8 | / | / | / | / | / | / | / | / | / | / | / | / | / |
| 23.1-26 | DW20Bx26 | 16 | 595 | 1605 | 738 | 4655 | 159 A8 | 2.3 | / | / | / | / | / | / | / | / | / | / | / | / |
| 11.2-28 | W10 | 8 | 295 | 1205 | 564 | 3615 | 118 A8 | 2.5 | / | / | / | / | / | / | / | / | / | / | / | / |
| 11.2-28 | W10 | 8 | 295 | 1205 | 564 | 3615 | 118 A8 | 2.5 | / | / | / | / | / | / | / | / | / | / | / | / |
| 12.4-28 | W11 | 8 | 323 | 1258 | 589 | 3774 | 123 A8 | 2.4 | / | / | / | / | / | / | / | / | / | / | / | / |
| / | / | / | / | / | / | / | / | / | / | / | / | |||||||||
| / | / | / | / | / | / | / | / | / | / | / | / | |||||||||
| 14.9-28 | W13 | 8 | 386 | 1375 | 644 | 4125 | 130 A8 | 1.8 | / | / | / | / | / | / | / | / | / | / | / | / |
| 14.9-28 | W13 | 12 | 386 | 1375 | 644 | 4125 | 138 A8 | 2.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 16.9-28 | W15L | 12 | 429 | 1435 | 672 | 4305 | 143 A8 | 2.4 | / | / | / | / | / | / | / | / | / | / | / | / |
| 16.9-28 | W15 | 8 | 435 | 1435 | 672 | 4305 | 135 A8/B | 1.7 | / | / | / | / | / | / | / | / | / | / | / | / |
| 16.9-30 | W15 | 8 | 440 | 1490 | 697 | 4470 | 137 A8 | 1.7 | / | / | / | / | / | / | / | / | / | / | / | / |
| 18.4-30 | W16L | 8 | 465 | 1564 | 732 | 4692 | 139 A8 | 1.4 | / | / | / | / | / | / | / | / | / | / | / | / |
| 18.4-30 | W16L | 14 | 465 | 1555 | 723 | 4665 | 151 A8 | 2.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 18.4-30 | W16L | 12 | 465 | 1564 | 732 | 4692 | 149 A8 | 2.3 | / | / | / | / | / | / | / | / | / | / | / | / |
| 18.4-30 | W16L | 14 | 465 | 1555 | 723 | 4665 | 151 A8 | 2.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 23.1-30 | DW20B | 12 | 587 | 1707 | 750 | 5120 | 151 A8 | / | / | / | / | / | / | / | / | / | / | / | / | / |
| 16.9-34 | W15 | 8 | 435 | 1585 | 742 | 4755 | 139A6 | 1.7 | / | / | / | / | / | / | / | / | / | / | / | / |
| 16.9-34 | W15 | 14 | 435 | 1585 | 742 | 4755 | 149 A8 | 2.8 | / | / | / | / | / | / | / | / | / | / | / | / |
| 18.4-34 | W16L | 8 | 465 | 1650 | 772 | 4950 | 142 A8 | 1.4 | / | / | / | / | / | / | / | / | / | / | / | / |
| 18.4-34 | W16L | 12 | 465 | 1650 | 772 | 4950 | 150 A8 | 2.3 | / | / | / | / | / | / | / | / | / | / | / | / |
| 18.4-34 | W16L | 14 | 465 | 1650 | 772 | 4950 | 126 A8 | 2.5 | / | / | / | / | / | / | / | / | / | / | / | / |
| 12.4-36 | W11 | 12 | 325 | 1465 | 694 | 4545 | 135 A8 | 3.5 | / | / | / | / | / | / | / | / | / | / | / | / |
| 13.6-36 | W12 | 8 | 350 | 1535 | 718 | 4605 | 129 A8 | 2 | / | / | / | / | / | / | / | / | / | / | / | / |
| 12.4-38 | W11x38 | 8 | 315 | 1515 | 715 | 4655 | 135 A8 | 3.9 | / | / | / | / | / | / | / | / | / | / | / | / |
| 13.6-38 | W12 | 8 | 350 | 1585 | 742 | 4755 | 131 A8 | 2 | / | / | / | / | / | / | / | / | / | / | / | / |
| 15.5-38 | W14 | 12 | 400 | 1577 | 738 | 4731 | 141 A8 | 2.3 | / | / | / | / | / | / | / | / | / | / | / | / |
| 15.5-38 | W14 | 10 | 400 | 1577 | 738 | 4731 | 137 A8 | 2.3 | / | / | / | / | / | / | / | / | / | / | / | / |
| 16.9-38 | W15L | 10 | 429 | 1685 | 789 | 5055 | 143 A8 | 2 | / | / | / | / | / | / | / | / | / | / | / | / |
| 18.4-38 | W16L | 12 | 465 | 1750 | 819 | 5250 | 152 A8 | 2.3 | / | / | / | / | / | / | / | / | / | / | / | / |
| 20.8-38 | W18 | 10 | 535 | 1840 | 830 | 5610 | 152 A6/148 A8 | 1.5 | / | / | / | / | / | / | / | / | / | / | / | / |
