| Size | Rim | Ply Rating | Inflated tyre dimension | Static Loaded Radius | Rollin Circum. | Load Index | Inflated Pressure | Recommended load, kg | ||||||||||||
| SW | OD | Speed | bar | Speed, (km/h ) | ||||||||||||||||
| (mm) | (mm) | (mm) | (mm) | Symbol | Free Rolling | Drive wheel | ||||||||||||||
| 10 | 20 | 25 | 30 | 40 | 50 | 10 | 20 | 25 | 30 | 40 | 50 | |||||||||
| 10.0/80-12 | 9″ | 8 | 259 | 710 | 328 | 2130 | 116 A8 | / | / | / | / | / | / | / | / | / | / | / | / | / |
| 10.0/75-15.3 | 9″ | 14 | 264 | 770 | 347 | 2272 | 130 A8 | / | / | / | / | / | / | / | / | / | / | / | / | / |
| 11.5/80-15.3 | 9.00 | 16 | 297 | 855 | 376 | 2485 | 141 A8 | / | / | / | / | / | / | / | / | / | / | / | / | / |
| 11.5/80-15.3 | 9.00 | 14 | 297 | 855 | 376 | 2485 | 139 A8 | / | / | / | / | / | / | / | / | / | / | / | / | / |
| 12.5/80-15.3 | / | 14 | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / | / |
| 12.5/80-15.3 | 9″ | 12 | 305 | 900 | 414 | 2700 | 140 A8 | 3.6 | / | / | / | / | / | / | / | / | / | / | / | / |
| 400/60-15.5 | AG13.00 | 14 | 405 | 875 | 385 | 2575 | 145 A8 | / | / | / | / | / | / | / | / | / | / | / | / | / |
| 12.5/80-18 | 11×18 | 16 | 318 | 980 | 435 | 2842 | 148 A8 | 4.9 | / | / | / | / | / | / | / | / | / | / | / | / |
