| Size | Rim | Ply Rating | Inflated tyre dimension | Static Loaded Radius | Rollin Circum. | Load Index | Inflated Pressure | Recommended load, kg | ||||||||||||
| SW | OD | Speed | bar | Speed, (km/h ) | ||||||||||||||||
| (mm) | (mm) | (mm) | (mm) | Symbol | Free Rolling | Drive wheel | ||||||||||||||
| 10 | 20 | 25 | 30 | 40 | 50 | 10 | 20 | 25 | 30 | 40 | 50 | |||||||||
| 6.00-16 | 94 | 8 | 4.5 | TT | / | 165 | 745 | 670 | 4.6 | A8/40 kmph | / | |||||||||
| 7.50-16 | 103 | 8 | 5.5 | TT | / | 205 | 808 | 875 | 3.8 | A8/40 kmph | / | |||||||||
| 9.00-16 | 116 | 10 | 7 | TT/TL | / | 234 | 854 | 1250 | 3.9 | A8/40 kmph | / | |||||||||
| 10.00-16 | 119 | 10 | 7 | TT/TL | / | 275 | 900 | 1360 | 2.9 | A8/40 kmph | / | |||||||||
| 11.00-16 | 124 | 12 | 10 | TT/TL | / | 320 | 970 | 1600 | 2.5 | A8/40 kmph | / | |||||||||
| 7.50-18 | 106 | 8 | 5.5 | TT | / | 204 | 867 | 950 | 3.8 | A8/40 kmph | / | |||||||||
