| Size | Rim | Ply Rating | Inflated tyre dimension | Static Loaded Radius | Rollin Circum. | Load Index | Inflated Pressure | Recommended load, kg | ||||||||||||
| SW | OD | Speed | bar | Speed, (km/h ) | ||||||||||||||||
| (mm) | (mm) | (mm) | (mm) | Symbol | Free Rolling | Drive wheel | ||||||||||||||
| 10 | 20 | 25 | 30 | 40 | 50 | 10 | 20 | 25 | 30 | 40 | 50 | |||||||||
| 320/85R28 (12.4R28) | 124A8/124B | / | 43 | 11 | 1258 | 321 | / | / | 160 | 1600 | ||||||||||
| 420/85R28 | 13A8/139B | / | 48 | 15 | 1438 | 439 | / | / | 160 | 2430 | ||||||||||
| 800/65R32 | 178A8/178B | / | 57 | 25 | 1833 | 797 | / | / | 320 | 7500 | ||||||||||
| 420/85R34 (16.9R34) | 142A8/142B | / | 48 | 15 | 1594 | 439 | / | / | 160 | 2650 | ||||||||||
| 600/65R34 | 151D/154A8 | / | 49 | 18 | 1665 | 607 | / | / | 160 | 3620 | ||||||||||
| 420/85R38 (16.9R38) | 144A8/142B | / | 48 | 15 | 1667 | 439 | / | / | 160 | 2800 | ||||||||||
| 460/85R38 (18.4R38) | 149A8/149B | / | 50 | 16 | 1737 | 470 | / | / | 160 | 3250 | ||||||||||
| 580/70R38 | 155A8/155B | / | 51 | 18 | 1822 | 580 | / | / | 160 | 3875 | ||||||||||
| 480/80R46 | 158A8/158B | / | 49 | 16 | 1971 | 490 | / | / | 240 | |||||||||||
