| SIZE | LOAD INDEX/ SPEED SYMBOL | STD. RIM | TREAD DEPTH | SECTION WIDTH MM | OVERALL DIAMETER | MAX LOAD | PRESSURE | ||
|---|---|---|---|---|---|---|---|---|---|
| kgs | lbs | kPa | PSI | ||||||
| 215/75R17.5 | 135/133 L | 6.00 | 12.5 | 211 | 767 | 2180 | 2060 | 860 | 860 |
| 285/70R19.50 | 150/148 K | 8.25 | 13 | 283 | 895 | 3350 | 3150 | 900 | 900 |
| 11R22.5 | 148/145 M | 8.25 | 17 | 279 | 1054 | 3150 | 2900 | 840 | 840 |
| 12R22.5 | 152/149 L | 9.00 | 17 | 300 | 1085 | 3550 | 3250 | 930 | 930 |
| 275/70R22.50 | 148/145 M | 8.25 | 14.5 | 276 | 958 | 3150 | 2900 | 900 | 900 |
| 275/70R22.50 | 148/145 M | 8.25 | 14.5 | 276 | 958 | 3150 | 2900 | 900 | 900 |
| 295/60R22.5 | 150/147 L | 9.00 | 14.5 | 292 | 926 | 3350 | 3075 | 900 | 900 |
| 295/80R22.5 | 154/149 M | 9.00 | 16 | 298 | 1044 | 3750 | 3250 | 850 | 850 |
| 315/70R22.5 | 156/150 L | 9.00 | 15.5 | 312 | 1014 | 4000 | 3350 | 900 | 900 |
| 315/80R22.5 | 156/153 L | 9.00 | 17 | 312 | 1076 | 4000 | 3650 | 850 | 850 |
