| SIZE | LOAD INDEX/ SPEED SYMBOL | STD. RIM | TREAD DEPTH | SECTION WIDTH MM |
OVERALL DIAMETER | MAX LOAD | PRESSURE | ||
|---|---|---|---|---|---|---|---|---|---|
| kgs | lbs | kPa | PSI | ||||||
| 11R22.5 | 146/143 K | 8.25 | 20 | 279 | 1065 | 3000 | 2725 | 850 | 850 |
| 295/80R22.50 | 152/149 M | 298 | 22 | 298 | 1044 | 3550 | 3250 | 900 | 900 |
| 315/70R22.50 | 156/150 L | 9.00 | 20 | 312 | 1014 | 4000 | 3350 | 900 | 900 |
| 315/80R22.5 | 156/153 L | 9.00 | 23 | 312 | 1076 | 4000 | 3650 | 850 | 850 |
